1. Trigger at the neutral position
( s t op)
(forward)
4. Push the trigger
(breaking)
CAR-TRANSMITTER BINDING:
As standard, transmitter and receiver are already bound or associated. Just turn on the
transmitter first, followed by the car and it will work. If necessary, BINDING can be done by
following these simple instructions.
- Put the batteries in the transmitter without turning it on.
- Put the match line provided on the channel BIND/CH3 of the receiver.
- Change the connector coming from the ESC and was in position CH2 to channel VCC.
- Connect the receiver battery.
- Now the light flashes on the receiver. That means that the receiver is going to the match status.
- Press and hold the 'bind' button on the transmitter and then switch on the power supply. The green light
flashes.
- The light of the receiver has to be fixed at the time, indicating that it is synchronized.
- Disconnect the transmitter and the receiver battery.
- Remove the match line from the receiver BIND/CH3 channel and replace the ESC connector on the channel
CH2.
- To launch the transmitter. At that time, the green li ght stops blinking, indicating that synchronization was
successful.
- If no synchronized correctly, please redo the process indicated.
2. Pull the trigger
(decelerate)
5. Release the trigger
to neutral
3. Back to neutral
6. Push the trigger
(backwards)
8
