3 Product description

RX series
The is designed as a
Unpack - plug in - ready!
RX-solar modules are sewn into a textile enclosure. In the fastening
edge of the modules 9mm eyelets are inserted, so that the module
Pic
can attach almost anywhere (
The soft transition from the rigid module to the textile frame and the
usage of plastic eyelets prevents the damage to the bearing
surface.
Each wing of a multi-wing module works independently.
This reduces power loss in case of partial shading.
Exception: fold able panels as RX-21052.
Both connection types have after long test series proved to be a
permanent solution at thousands of folding operations.
Panel components (Pic ture 1):
Cable outlet:
Socket sealed sea watertight and screwed to
mounting plate
Mounting strap
Textile frame
9mm plastic eyelets
5
Textile joint
(of multi-wing modules)
6
SureSeal-connector
7
FOX-062 Charge Controller
11
plug & play solution
.
ture , Point 1 4
).

4 Electrical connection

For use and electrical connection
required!
T he panel comes with a 5m long cable with SureSeal plug mounted
(Picture 2).
This connector just plug in the socket on the accompanying charge
controller FOX-062 (Picture 3)
socket or cigarette lighter - done.
Picture 4 shows schematically the electrical connection.
As accessory we offer matching plug-in extension cables in 5m and
10m length.
Further details regarding the charge regulator FOX-062 can be
found in the enclosed installation instructions for FOX-062.
of the panels no tools are
. The FOX-062 stuck in the vehicle
