INTRODUCTION
GENERAL SAFETY INSTRUCTIONS
SPECIFICATIONS
VACUUM PUMP OPERATION
ROUTINE MAINTENANCE
TROUBLE SHOOTING CHART
WARRANTY & CONTACT INFORMATION
Thank you for purchasing the CPS® PRO-SET® VP series vacuum pump. The
VP series vacuum pumps have been specifically designed for air-conditioning
and refrigeration service work. The VP series utilizes an electrical motor and
oil filled rotary vacuum pump cartridge.
The following are additional features:
• 2 Stage operation - provides a higher evacuation level and faster
evacuation times
• Multi-voltage operation - the vacuum pump can be quickly converted
to 115 or 230-volt operation.
• Sure grip handle - ergonomically designed for portability. Also functions
as the exhaust of the vacuum pump on VP4 and VP6.
• Gas Ballast valve - when used, reduces the amount of moisture contained
in the vacuum pump oil.
• Isolation Valve - allows the vacuum pump to be isolated from the system
being evacuated, allows user to check for leaks (not used in VP2).
• Oil Drain port - for easy vacuum pump oil maintenance.
• Vacuum Pump Oil Level sight glass - visual check for oil level & oil purity.
To help you get a good start, please continue to carefully read the balance of
this manual. This manual contains important information on the proper
procedures for operating this equipment. Please pay close attention to the
safety information, Warnings, and Cautions provided throughout this manual.
Always remember "Safety First".
UNIT CONSIST OF:
• Pro-Set® model VP2, VP4 or VP6 vacuum pump
• Power Cord Set (115 volt)
• 1 quart (VP4, VP6) or 1 pint CPS vacuum pump oil (VP2)
• Operation Manual
TABLE OF CONTENTS

INTRODUCTION

2
2, 3
4
5
6
6
7
8
