8 Commissioning / functional test

• The following sections describe testing the functioning of the inputs/outputs.
It is recommended to test together with the connected system. The pump's
installation and operating instructions are needed for some settings.

8.1 General settings

• Set the bus address in the pump menu 5.2.3.0
• Set baud rate with parameter A in the pump menu 5.2.4.0 in accordance with
the following table:
Parameter A
0
1
2
3
4
5
6
7
8
9
Additional baud rates may be defined in the relevant protocol description.
28
Baud rate
300
600
1200
2400
4800
9600
19200
38400
57600
115200
WILO SE 11/2013
