4. Standard Mounting Instructions
Mounting Installation
Please see the User Manual for detailed instructions regarding installation and mounting
of the camera using a mounting bracket.
Style 1 - Concealed Cable Installation
ƒ Height: 25.6 mm (1.0 inches)
ƒ Diameter: 122 mm (4.8 inches)
ƒ Weight: 135 g (0.3 lbs)
Weather shield
screw
D-Link DCS-6314 Quick Install Guide
Figure 2.1
Weather Shield
Figure 2.2
