DMx LINKING:

DMx-512
DMX (Digital Multiplex) is a universal protocol used as a form of communication between intelligent fixtures
and controllers. A DMX controller sends DMX data instructions from the controller to the fixture. DMX data
are sent as serial data that travel from fixture to fixture via the "DMX IN" and "DMX OUT" XLR terminals
located on all DMX fixtures (most controllers only have a "DMX OUT" terminal).
DMx LINKING:
DMX is a language allowing all makes and models of different manufactures to be linked together and operate
from a single controller, as long as all fixtures and the controller are DMX compliant. To ensure proper DMX data
transmission, when using several DMX fixtures try to use the shortest cable path possible. The order in which
fixtures are connected in a DMX line does not influence the DMX addressing. For example a fixture assigned to a
DMX address of 1 may be placed anywhere in a DMX line, at the beginning, at the end, or anywhere in the midd-
le. When a fixture is assigned a DMX address of 1, the DMX controller knows to send DATA assigned to address 1
to that unit, no matter where it is located in the DMX chain.
Please check out our comprehensive DMX cable choices out of our Adam Hall product lines 3 STAR, 4 STAR and 5 STAR
Keep in mind that DMX connections must be daisy chained. To avoid malfunction, DMX cabling should not be
divided in several lines without the use of an active splitter.
