DMx CONTROL MODE:
7 CHANNEL MODE
CHANNEL
CH3
CH4
CH5
CH6
CH7
DAISY CHAIN CONNECTION
1) Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture
2) Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the
input connector of the next fixture consisting of a (male) 3 pin connector. Proceed to connect from the output as
stated above to the input of the following fixture and so on.
14
VALUE
000 - 255
000 - 255
000 - 255
000 - 255
000 - 080
000
001 - 004
005 - 010
011 - 015
016 - 020
021 - 025
026 - 030
031 - 035
036 - 040
041 - 045
046 - 050
051 - 055
056 - 060
061 - 065
066 - 070
071 - 075
076 - 080
081 - 150 Colour Jumping Speed: slowest (081), fastest (150)
151 - 220 Colour Fading Speed: slowest (151), fastest (220)
221 - 255
FUNCTION
RED (0-100%)
GREEN (0-100%)
BLUE (0-100%)
AMBER (0-100%)
Colour-Macro
Colourmix CH3 - CH6
Blackout
Red
Green
Blue
Amber
Yellow
Cyan
Lavender
Pink
Bright Green
Magenta
Turquoise
Orange
Bright Magenta
Cold White
Warm White
Sound Control (Mic Sensitivity)
