AAVA MOBILE Inari 6 Flip e355 Kurzanleitung

Inari 6 Flip e355 Quick Start Guide
Inari features, buttons & interfaces
Front
4
3
2
5
6
1
8
7
1 Charging indicator LED
OFF not connected to charger
ORANGE charging
GREEN connected and fully charged
RED charge fault
2 Front camera
3 On / Off Button
Push it once to start the tablet; push it again to enable the sleep mode. Push
and hold it to shut down the device.
4 Volume key or programmable buttons
Volume: left side to reduce volume, right side to increase volume
Buttons can be also programmed for instance to control scanner
5 Front receiver
6 Ambient Light Sensor & proximity sensor
ALS recognizes the ambient light and adjusts the display brightness if enabled
in the operating system; PS recognizes if device is held to ear or in pocket
7 Front microphone outlet
8 Front speaker
Bottom side
10
9
e355 Flip
11
9 Charging pads
10 USB-C
1
11 2D scanner (optional)
1
Tablet available with or without 2D scanner
Rear view
e355 Flip
12
13
12 Safety screw to fix verifone e355 payment terminal
13 Docking connector for verifone e355 payment terminal
Replacing Battery / Adding payment terminal
To replace the battery, unscrew the battery lid by rotating the lid
counterclockwise. Remove the empty battery and replace it with a new one.
Please pay attention to the insertion direction which is shown in the graphic
below.
Please note that the verifone e355 payment terminal is not part of the delivered
product. Please ensure the WiFi connection of the e355 is turned off when used
inside the Inari 6 Flip product.
Insert the verifone e355 payment terminal on the rear side of the product into
the payment terminal holder. Make sure that the payment terminal has clicked-in
to be safely connected. To use the e355 payment terminal, please follow the
instructions of the e355 handbook.
Using the Device for the first time
1. Connect power supply for the first time and make sure battery is fully
charged before disconnecting.
2. Press the power button
3. Follow the instructions in the operating system to complete the setup
Troubleshooting
In case devices freezes and you need to do a hard reset, press and hold the power button for
approx. 14 seconds. Device will be turned off now.
Connecting USB3.0 devices while being connected to a WLAN network requires it to be a 5GHz
connection to maintain it. 2.4GHz networks will be disconnected on the Inari 6 side while
USB3.0 devices are in use.
Important Product and Safety information
•
Do not drop, bend or twist your tablet. This can break tablet display glass, internal
circuit boards or mechanics. If the glass breaks, do not touch the glass parts of the
device or attempt to remove the broken glass from the device. Stop using the device
until the glass is replaced by qualified service personnel.
•
Do not try to disassembly your tablet. This may damage the device.
•
Operate your device in a place where temperature is between -10°C and +50°C.
•
Charge your device with the recommended charger in a place where temperature is
between +10°C and +40°C.
•
Store your device in a place where temperature is between -20°C and +60°C.
•
This product is equipped with USB-C connector, intended to be supplied by certified
power supply capable of providing 5V-12V according to USB specification
•
For charging the socket-outlet shall be installed near the equipment and shall be easily
accessible.
•
Protect your device from water and moisture intake. Keep connector doors closed
when not in use to prevent water and moisture intake.
•
Use only soft, clean and dry lint-free cloth to clean your device.
•
Keep the unit and accessories away from small children.
•
Switch off your device before boarding to an aircraft.
•
Switch off your device in any area with a potentially explosive atmosphere.
•
Your device meets guidelines for exposure to radio waves (SAR, Specific Absorption
Rate) when kept in a close distance to your body.
•
Use only charger recommended for use with your tablet.
•
Power rating main battery inside flip hinge: 3.6V --- 4.8A
•
Power rating core battery: 3.8V --- 2.25A
•
Do not disconnect charger by pulling the cord.
•
Do not use damaged power cords or plugs.
•
Save energy. You can save energy by doing following.
o Close unused applications and data connections.
o
Decrease screen brightness and sound volume.
o Deactivate unnecessary sounds like touch panel sound.
o
Disconnect your charger from mains outlet when charger is not needed.
o
Do no keep unnecessary accessories connected in your device.
•
Recycle. Return your used electronic units to dedicated collection points. Please note
that your tablet has a battery, so it is not allowed to be disposed to normal household
waste and battery requires separate recycling.
•
Replaceable battery safety
o
Batteries have life cycles. If the time that the battery powers equipment
becomes much shorter than usual, the battery life might be at the end.
o
Fully charge the battery at least every 6 months.
o Stop using the tablet if abnormal heat, order, discoloration, deformation, or
abnormal condition is detected during use, charge, or storage.
o
Keep the device away from heat (battery temperature not to exceed 60°C).
o Do not throw battery into fire, it may be exploded.
o
Do not soak the battery with liquid like water, tea, coffee etc.
o Do not hit, bend, deform or drop the battery.
o
Do not pierce battery with a sharp object such as a needle, etc.
o The battery should not have liquid from electrolyte flowing, but in case the
electrolyte come into contact with eyes, don't rub your eyes. Wash your eyes
well with clean water and go to see a doctor immediately. In case the
electrolyte come into contact with your skin, wash it well with clean water.
o
Do not externally short-circuit the battery. If externally short-circuited, the
battery may be heated, ignited or broken.
o
There is a risk of explosion if you replace the battery with an incorrect type.
Only use the correct battery type for this device.
o
Dispose of battery needs to be done according to instructions above.
Warning Statements
To prevent possible hearing damage, do not listen at high volume levels for
long periods.
