7� STOP button with LED
8. Sliding switch for melody selection for the
signal alarm in respect of the connected
telephone
9� Sliding switch for melody selection for the
signal alarm in respect of the connected
doorbell pick-up
10� Telephone line connection port
11� Power adapter plug connection port
12� Telephone connection port
13� Vibration pad connection port (option)
14� Sliding control for the signal alarm volume
15� Sliding switch to select type of signal
alarm
Connecting the base station
Connect the RingFlash 250 base station
as illustrated in the diagram� For reasons
of safety, only use the power adapter plug
and telephone connection cable contai-
ned in the material supplied�
Telephone
line socket
Telefonanschlussdose
1� Disconnect the existing telephone con-
nection line from the phone currently
used�
2� Connect the end of the telephone cable
just disconnected in the telephone line
port LINE (10) in the RingFlash 250 base
station�
3� Then plug the telephone line supplied in
your telephone.
Service−Hotline: Tel. 0844 800 6503
Using the RingFlash 250
Power outlet
Netzsteckdose
