Blumfeldt 10029439 Handbuch Seite 8

1. Select an area of flat ground for the tent.
Unpack the carton and check all parts
including tubes, tent and accessories...
etc. are present. Assemble the rooftop
framework by joining the (6,7,8,9)
Connectors together with poles (1,2,5).
Ensure the tension screw is fixed to every
pole tightly.
2. Attach one end of the support poles (4)
to the roof joints (6,7).
3. Place roof on frame, and attach with
bungee fixings, take care not to over
tension bungee, as this may cause
difficulty correctly fitting roof.
Assemblage
8
