1 Antenna, with magnetic grounding tail attached
2 DAB film aerial
3 Controller with USB power and audio connectors
4 Controller bracket
Restrictions for use - to be used only with items shown on this page and configured/installed/used according to this manual.

Display icons

The icons below appear on the screen of the
controller.
1 2 3
4
4 5 6
5 Cleaning cloth
6 12V power adapter (dual USB port)
7 Self-adhesive cable clips
1 Digital radio mode
2 Digital radio signal strength
3 Traffic announcements enabled
4 Auxiliary input mode
5 FM transmit enabled
6 FM transmit frequency
