Installation and Operating Instructions
Dimplex Air Barrier - Modular Linking Kit
Model : CABM1 (suitable for use with all CAB & DAB Models)
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE.

IMPORTANT SAFETY ADVICE

DO NOT COVER OR OBSTRUCT the air inlet or outlet grille.
ENSURE THE APPLIANCE IS EARTHED.
Do not mount the
excessive dust exists.
Always disconnect supply before working on the
product.
This product should be mounted safely to solid wall or
ceiling surfaces only.
Ensure the supply cables are of adequate current
carrying capacity and are protected by a suitable fuse.
Ensure proper manual
observed at all times.
WARNING: Isolate electrical supply to ALL modular linked
units when carrying out maintenance.
The CAB Model requires:
1 x Modular joining cable
1 x CAB Joining label
3 x M8 x 70mm Bolts
3 x M8 nuts
3 x M8 shake-proof washers
3 x M10 x 40mm Bolts
3 x M10 nuts
3 x M10 shake-proof washers
4 x Cable clips
The Instructions for the Modular Linking Kit should be read
in conjunction with the 'Dimplex Air Barrier' Instructions. All
'Safety Advice' to be heeded before installing the appliances.
Note: As this Kit is applicable to both CAB and DAB models
there may be fasteners etc. left over depending on which
model it is used on.
Procedure
1. Decide which appliance is to be the master module and which
of the appliances are to be the slaves. To open the appliance
remove the outlet grille, bottom panel and the inlet grille - see
'CAB/DAB' Installation Instructions.
2. In order to attach the modular units together, the fixing holes (1-
3) as indicated in Fig. 1 must be drilled using an appropriate drill
size (CAB - 10.5mm dia & DAB - 8.5mm dia). The knock-out (x)
for the modular joining cable must also be removed. While
supporting the endcap, punch a series of small holes around
the perimeter of the knock-out from inside out, using a hammer
and flat bladed screw-driver.
Note : in Fig. 1 refers to extra hole on DAB models only.
*
3. Bolt modules together as shown using the supplied fixings -
see Fig. 2a & 2b.
4. Fit 25mm x 50mm unistrut (or similar - not supplied) supporting
members across the top of all bolted units which exceed 2
metres in length (see 'a' in Fig. 3) before mounting into position.
Otherwise link units when fixed in position.
5. Fix the self adhesive label between adjoining intake grilles - see
'b' in Fig. 4, ensuring that the small light grey bands on the label
line up with the fins on the inlet grille.
6. On Master Module remove the connector block from the M/S
OUTPUT socket (on right hand side) of Master Control board -
see Fig. 5.
7. Plug one end of the Modular joining cable into the
M/S OUTPUT socket (on right hand side) on the Master Control
board - see Fig. 6.
8. On the Slave Control board, remove MASTER link wire - see
Fig. 7.
appliance in areas where
handling procedures
The DAB Model requires:
1 x Modular joining cable
1 x DAB Joining label
3 x M8 x 70mm Bolts
4 x M8 x 40mm Bolts
7 x M8 nuts
7 x M8 shake-proof washers
4 x Cable clips
9. Run the
Control board through the knock-out hole to the adjoining Slave
Control board - see 'x' in Fig. 8.
Clip the cable using the supplied cable clips as shown - see
'y' in Fig. 8.
10. Plug in connecting block at the other end of the
joining cable to the Slave M/S INPUT socket (on left hand side) -
see Fig. 9.
11. Wire independent electrical supplies to each module -
see Fig. 11 for Electric Models,
and Fig. 12 for Water/Ambient models.
are
12. Replace the bottom panel and outlet grille assembly (see 'CAB/
DAB' Installation Instructions) and install the modular assembly
by fixing to adjacent wall brackets positioned as shown - see
Fig. 10.
Wiring Diagram (see Fig. 11)
Electric Models - CAB 'E' & DAB 'E'
A - Master Module Link
B - 12VDC Feedback Signal to BMS (Unit Fault Check)
C - Thermostat (Optional)
D - Door Switch (Optional)
E - Thermal Safety Cut-out Circuit
F - Elements
G - BMS Switches (Optional)
Note: If Switch Kit is used only connect to the Master Control
board.
Wiring Diagram (see Fig. 12)
Water/Ambient Models - CAB 'A' & DAB 'A'
A - Master Module Link
B - 12VDC Feedback Signal to BMS (Unit Fault Check)
D - Door Switch (Optional)
G - BMS Switches (Optional)
Note: If Switch Kit is used only connect to the Master Control
board.
Recycling
Cleaning
WARNING: DISCONNECT SUPPLY before carrying out
maintenance.
External appearance can be maintained by wiping occasionally with
a damp cloth ; for stain removal, a weak soap solution can be applied
with a cloth and the surface wiped dry. Care must be taken to avoid
any moisture ingress into the product.
After Sales Service
Should you require after sales service or should you need to purchase
any spares, please contact the retailer from whom the appliance
was purchased or contact the service number relevant to your
country on the warranty card.
Please do not return a faulty product to us in the first instance as this
may result in loss or damage and delay in providing you with a
satisfactory service.
Please retain your receipt as proof of purchase.
- 1 -
modular joining cable
CAB 'W' & DAB 'W'
