Info-Menü
MENU
INFORMATION PERSON
Submenu Software: shows current firmware version of the fixture.
Submenu Hardware: show current hardware versions of the fixture.
Submenu Fix times: shows current working time of the fixture.
Miscellaneous Settings
MENU
PERSON SETUP
Password: DOWN - UP - DOWN - UP - ENTER
ID number: sets ID of the fixture.
Display Led: sets if display illumination is always on (ON) or switches off automatically 10 seconds
after last display input (OFF).
Key locks: In this menu the password protection of the fixture is activated or deactivated. If set ON
the fixture is password protected when started. 30 seconds after the last setting the menu is locked
again. To be able to make changes in the menu the password DOWN - UP - DOWN - UP - ENTER
needs to be typed in.
Max temp: gives the user the possibility to set the max. acceptable temperature of the led unit,
before the intensity of the fixture is reduced.
NOTE:
A high max. acceptable temperature can reduce the life span of the led unit.
Dimmer CW/WW/ALL: limits the maximum brightness at the DMX value "255" for cool white
(Dimmer CW), warm white (Dimmer WW) or both values (Dimmer ALL).
NOTE: The maximum value can be limited to 0. In this case, a dimmer channel does not respond
to a sent DMX value, which can be misinterpreted as a device error.
HSIC
Software VX.X.X. 00
Hardware HSIC HX.X.X.
Fix times HSIC
XXXXXh XXm
ID number HSIC 1-66
Display Led
HSIC ON
OFF
Key locks
HSIC OFF
On
Max temp
HSIC
****
Dimmer CW HSIC 0-255
Dimmer WW HSIC 0-255
Dimmer ALL HSIC 0-255
