Installation
Mounting
Hanging
The device can be used in any position. On the mounting bracket are holes
available, for attaching standard brackets. Fixture must be safe mounted in
accordance with the relevant regulations and provided with a safetycord to
prevent falling. For this purpose, an eyelet for safeties is attached to the device.
NOTE
The LED module can be operated in any position.
DMX-Connection
Use specified DMX-cables to connect the units to each other and to connect them to the control-
desk. Enter the addresses and personalities to the units.
DMX Addr.1 DMX Addr.(Nx1)+1
DMX512
CONTROLLER
E-17
DMX Addr.(Nx2)+1
. . . . . . . . . . . .
