Setting DMX-Address
MENU MENU
PERSON DMX
The DMX start address of the fixture is set in the menu DMX, submenu Address. This is retained
even when changing the personality.
Setting DMX-Personality
MENU
PERSON DMX
The personality is set in the menu DMX, submenu Channel Mode. There are four different
modes which can be choosen: 2-, 3-, 4 -and 5-channels.
Edit Static Colours
MENU
STAT COLO
PERSON
Static colours for stand-alone operation are set in STAT COLO. These are mixed using the
DMX value scale 0-255 for cool white (STAT CW), warm white (STAT WW), overall colour
temperature (COLOR TEMP) and strobe 0-31 (STAT STROB).
Activating Auto Programs
MENU
AUTO
PERSON
In the menu AUTO, submenu AUTO MODE the automatic programs stored in the device
are activated. There are five fix automatic programs stored in the fixture (01-05). Additionally the
speed of the automatic programs can be controlled in 32 steps (00-31) in the submenu SPEED.
HSIC Address 1-512
Channel Mode HSIC 2/3/4/6
STAT CW HSIC 0-255
STAT WW 0-255
COLOR TEMP HSIC 0-255
STAT STROB HSIC 00 00-31
HSIC SPEED 00-31
AUTO MODE HSIC 01-05
E-19
