C. THE HELMET
MOUNTING THE CHEEK PAD
1. Push the A.R.O.S. strap through
the neck strap channel as far as the
chinstrap padding opening.
2. From the outside, thread the
chinstrap through the cheek
cushion and through the A.R.O.S.
strap and pull it tight from the back.
3. Zip up the zipper.
4. Mount the cheek pad using the three
pins on the red plugs and sockets.
Ensure that the head strap
cushion's plastic strap with the round
holes is inserted over the rear cheek
cushion pin.
82
5. Repeat points 1 to 4 to mount the
cheek pad on the other side.
6. Reinsert the neck collar by first
inserting the guide pins into the
front plugs and sockets on the lower
helmet edge on both sides and then
mount the neck collar into the guide
gap piece by piece.
Note:
Ensure that the A.R.O.S. straps are not twisted.
Note:
When inserting the crown liner, make sure that the headband
ventilation cut-outs are positioned over the ventilation channels
at the back of the helmet and that the crown liner runs centrally
between the two ventilation channels.
Caution:
Never ride when parts of the inner lining have been removed.
Caution:
Excessive heat (e.g. exhaust heat) can cause damage to the inner
lining!
Note:
To avoid damage to the inner lining and inner shell, do not hang the
helmet over the mirrors or handlebar grips.
