ADJUSTING THE SIGHT
Set the red dot to an optimum brightness using
the brightness control.
Remove the caps from the adjusting screws for
elevation and windage.
To change the point of impact, use a coin to
turn one of the screws in the required direction.
Each click of the sight adjustment changes the
point of impact.
1 click: 0.12 cm/10 m, max. 50 clicks/rotation,
1 rotation: 6 cm
Elevation adjustment
If shots group high,
turn the screw counter-clockwise
(UP direction)
If shots group low,
turn the screw clockwise
Windage adjustment:
If shots group to the right,
turn the screw clockwise (R direction)
If shots group to the left,
turn the screw counter-clockwise
Elevation adjustment
Windage adjustment
Elevation adjustment
Windage adjustment:
ON
