NOTES

MAINTENANCE

Protect your red dot sight against mechanical damage from knocks and make sure that the
firearm is not subjected to rough treatment. If you think something might have changed,
check the adjustment of the firearm. Remove dust and dirt from the housing and lens mount
with a soft cloth moistened with gun oil. To clean dust from the lens, use a soft lens brush.
Fingerprints and dirt can be removed from the lens with a lens cloth (moistened with lens
cleaning fluid).
DISPOSAL
Please note that flat batteries must not be put in the household waste.
Dispose of them properly, hand them in at your local shop for disposal or
take them to a used battery collection location. Do not recharge the batteries,
subject them to heat or throw them into a fire. Improper use can cause a life-threatening
explosion or chemical fire. If you do not intend to use the device for a long period, remove
the batteries and store them in a cool, dry place.

TECHNICAL DATA

DOT
4 MOA
ILLUMINATED
Magnificaton: 3x
Objective: 30 mm
Ocular: 26 mm
Focusing at the magnifier
Field of view 110 cm/10 m
Reticle adjustment:
1 click: 0.12 cm/10 m, max. 50 clicks/rotation
1 rotation: 6 cm/10 m
Brightness settings: 7
Energy source : 2x Batterie LR44
Weight of red dot sight including mount: 295 g
Length of red dot sight: 138 mm
Weight of magnifier including flip mount: 393 g
4
STEPS OF MOUNT FOR
LUMINANCE PICATINNY
WEAVER
7 RAIL
INCLUDED
MAGNIFICATION
A
BUTTON CELL
2
LR
3
44
X
EN
Li
