Install and use the DockingStation
The dock will automatically install some of the required drivers once it is connected to your
notebook's USB Type-C
follow the on-screen instructions to complete the installation.
Connect your devices to the appropriate ports on the DockingStation.
Connect your external display to the DockingStation's video port.
Note: Video output capabilities are dependent on the graphic card and
hardware specifications of your connected host laptop. Certain graphic
cards have limited MST support, while some monitors will also limit the
output resolution.
Configure a display device
Please setup your display settings accordingly to your operating system and requirements.
For detailed information, see the corresponding operation manual and description of your
operating system. Your laptop hardware must support external displays (e.g.: MST).
Supported video resolutions
The DockingStation supports 4K HD resolution if the connected HDMI
Number of displays
supported
1
Important:
1. When connecting the USB Type-C
Chromebook
work immediately; it will have seconds' delay. This problem also occurs in other
similar Type-C
with Chromebook
2. Attention! When plugging in and out a PD 2.0 adapter to the Type-C
interface of the IB-DK4038-CPD, the connected USB devices will get disconnected
flashily and then reconnect in a few seconds, so to prevent possible data loss or
corruption, avoid (dis-)connecting the PD 2.0 adapter from AC power while
transferring data.
Manual IB-DK4038-CPD
port. If you receive a prompt to automatically install the driver(s),
™
Video output
configuration
HDMI
®
, the mouse to be connected to the USB 3.0 Type-A port will not
™
adapter (including Apple original 3 in 1 adapter) when connected
™
.
™
plug of the IB-DK4038-CPD to a
™
display supports it.
®
Maximum
resolution/monitor
3820x2160p@30 Hz
™
