Netzspannung
Netzschalter
6
Verstärkungs-Trim
5
6
~ 115V AC / ~230V AC, 50 Hz / 60 Hz, P max. 1375VA
C A U T I O N
RISK OF ELECTRIC SHOCK
D O N O T O P E N
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
Made in Germany
Lautsprecher-Anschluss
8
Slave Thru
9
7
TRIM
XLR WIRING:
Pin 1 = GND
Pin 2 = Hot (+)
Pin 3 = Cold (–)
THRU
INPUT
INPUT
+
Minimum Load:
2
SPEAKER OUTPUT
Performer m1000
Serial
Number
230V AC:
Connect to
T 6.3 A
1. Remove Fuse Holder
AMP CTL output of
L 250 V
2. Exchange Fuses
SPL Preamplifier/DAC
for remote power on/off
115V AC:
3. Flip Over
OR
T 12.5 A
4. Reinstall
Use 12 V Trigger
L 250 V
FUSE
VOLTAGE SELECTION
AMP CTL/12V TRIGGER
11
I
F R
Eingang
–
spl.audio
10
AMP CTL
Rückansicht
