Maintenance - bürkert ELEMENT Bedienungsanleitung

a)
b)
English
12
fitting the cover on the measuring
device
English
14
→
The module can be
fitted in 4 different
positions, at 90°
intervals.
c)
d)
→
Fully push in the
module and, using
the palm of your
hand, turn to the
right to lock it.
→
Check that there is a
seal on the cover and
that it is not damaged.
Replace it if necessary.
→
Grease the seal if nec-
essary using a com-
ponent compatible with
the material from which
it is made.
→
Fully tighten by hand to
guarantee tightness.
Removing the display module
20°
ADjusTMENT of ThE
MEAsuRiNg DEVicE
Refer to the user manual of the ELEMENT measuring
device to learn about the details on adjustment using the
display module.

MAiNTENANcE

The display module can be cleaned with water or using a
detergent compatible with the materials from which it is
made.
Please feel free to contact your Bürkert supplier for any
additional information.
→
Unscrew the cover if nec-
essary (see page 10).
→
Place the palm of your
hand flat on the module
and turn by ca. 20° to the
left. Once unlocked, the
module is raised slightly
by the spring action.
→
Remove the module from
its housing.
