7.3 Battery
Information!
The batteries are not charged at the factory.
Therefore:
– Charge the batteries before using for the first time.
Information!
Limited temperature range for charging and storing the batteries.
Therefore:
– It is imperative that the operating instructions for the battery charger are complied with.
Removing the battery (Fig. 2)
Push in (1) the two release buttons (A) and then remove the battery (2).
Inserting the battery (Fig. 3)
Slide the battery into the device as illustrated until it clicks into place.
Battery charge indicator (Fig. 1)
The 4 green LEDs (6) indicate the charge level of the battery. The number of LEDs lit up denotes the
battery charge. If the LED (5) is flashing the battery is empty and no further crimp is possible.
7.4 PowerCrimp and battery
Information!
The PowerCrimp crimping device must only be operated with 12 V lithium-ion
rechargeable batteries.
Behaviour of the crimping device after extended periods out of use or when changing the battery:
If the crimping device is out of use for approx. 30 minutes or the battery is reinserted, it switches off. No
LED is lit up any longer. Press the start button (1) briefly to turn on the crimping device.
Behaviour of the crimping device when the battery is empty:
If the green LED (5) is flashing the battery is empty and no further crimp is possible. The battery must be
recharged.
8

Commissioning and operation

Strip an appropriate length of cable.
8.1 Preparing the PowerCrimp
CAUTION!
Fingers risk being crushed if the device is operated without a crimping inserts
(Fig. 4)
If no crimping insert is fitted, fingers could be placed in the at-risk zone. Fingers could be
crushed when the device is started.
Therefore:
– Do not operate the device without the crimping insert.
– Keep your fingers away from the at-risk zone.
