6. Commissioning, operation
Index Object
(decimal) name
240 MBA
241 MBE
250 DISR
251 DISM
252 PAS
253 LOCK
Index Object name
(decimal)
2 RES
2 LOCK
2 UNLOCK
2 RHL
2 0SET
WIKA operating instructions pressure switch model PSA-31
Format Access Value range
32 Bit IEEE R -
754 Float
32 Bit IEEE R -
754 Float
8 Bit R/W 0 = Standard
Enumeration 1 = 180° rotated
8 Bit R/W 0 = Act
Enumeration 1 = HIGH
2 = LOW
3 = SP1/FH1
4 = RP1/FL1
5 = SP2/FH2
6 = RP2/FL2
7 = Off
16 Bit R/W 0 ... 9,999
unsigned
8 Bit R/W 0 = Unlocked
Enumeration 1 = Locked
Value Remarks
130 Return the set parameter to the factory settings
163 General keylock On
164 General keylock Off
176 Clear the Min- and Max-value memories
177 Zero-point adjustment (3 % of span) see page 17
Factory set- Remarks
ting
1,000 The pressure value is
always linearised such
that the MBA equals the
value 1,000 and the MBE
equals the value 9,000.
9,000 The pressure value is
always linearised such
that the MBA equals the
value 1,000 and the MBE
equals the value 9,000.
0 Turn display indicator
by 180°
0 Display value in display
mode
- Enter password in order
to set the parameters at
the instrument. Password
0 = no password
0 General keylock
