Important: Changes in the settings marked with
Selectrix mode of operation automatically lead to changes in the
DCC mode of operation and vice versa!
Settings for different parameters:
CV Description
1 Adress
3 Acceleration delay
4 Braking delay
5 Maximum speed
*
17 Extended adress (upper part)
18 Extended adress (lower part)
Bit 0: Travel direction polarity reversal + lighting
29 Bit 1: Number of speed level 14/28
Bit 5: Adress size 7 bit / 14 bit
49 Pulse width for motor control
*
50 Rule variant
*
Bit 0: Motor polarity reversal
51 Bit 1: Only lightning
*
Bit 2: Track Polarity reversal
Other changes are not possible. The values set at
the factory have been selected to insure trouble-free
operation.
for the
*
DCC Value
1 - 99
0 - 127
0 - 127
1 - 7
CV 29 Bit 5 = 1
CV 29 Bit 5 = 1
0/1
0 - 3
0 - 3
0/1
The operating instructions for your central unit (example:
Central Control 2000) will give you exact procedures for
setting the different parameters. With many systems the
values set at the factory can be read in the programming
mode.
Selectrix Value
1 - 99
1 - 7
1 - 7
1 - 7
not necessary
not necessary
not necessary
1 - 4
1 - 4
not necessary
