USRobotics Wireless MAXg ADSL Gateway Installationsanleitung Seite 13

Gateway Back
ADSL
Digital subscriber line RJ-11 service jack
USB Port that accepts a USB cable to a printer.
1 - 4 Ethernet ports 1 - 4
Reset A recessed button that resets the gateway (see note below)
9VDC Input jack that accepts a cable from supplied power adapter
Power Rocker switch that turns the gateway on and off
NOTE: To reset the gateway, insert a pin or paper clip to briefly push the Reset
button. If you want to reset the gateway, do not press this button for more than
5 seconds, as this resets the gateway's configuration to the factory defaults.
11
