The LED display

The various operating statuses of the LV102 are indicated by the
LEDs on the front plate:
LED shines constantly Everything ok, device in normal operation
LED flashes slowly
LED flashes quickly
LED double-flashes:
Terminals C and D are not connected
or
Emergency stop, track voltage switched off at
an operating device
or
The command station is not ready for
operation
Emergency stop, track voltage switched off
or
Overheating of amplifier
or
Transformer not connected to U,V (correct)
but to J,K (incorrect).
The LED will also flash quickly when the
LV102 is switched off, this is normal.
A programming procedure was started by
means of PoM (see "Setting the track
voltage")
