Specification Summary; Using Your Headset - Asus Cerberus Schnellstartanleitung

Specification summary

• Frequency response: 20Hz~20kHz
• Speaker driver: 60mm neodymium magnet speaker drivers
• Impedance: 32 ohms
• Ear cups: 100mm large ear cups with ultra breathable material
• Connectors: 3.5mm 4-pole analog connector (smart devices)
• Extension: 3.5mm 3-pole analog headphone & microphone Y-cable
connector
• Microphone boom: -40dB sensitivity unidirectional microphone boom
• In-line microphone: -45dB sensitivity omnidirectional microphone

Using your headset

NOTE: There are L and R markings on the ear cups.
Connecting to smart devices
• C onnect your headset's analog connector into your smart device such as
mobile phone or tablet PC.
• U se the in-line controllers to increase/decrease the volume or mute the
microphone.
Connecting to PC or MAC
1. Connect your headset's analog connector into the bundled Y-cable.
2. C onnect the Y-cable's headphone connector to your computer's
headphone port.
C onnect the Y-cable's microphone connector to your computer's
microphone port.
3. Y ou can connect the bundled microphone boom to your headset.
NOTE: The in-line microphone is disabled when the microphone
boom is connected.
4. U se the in-line controllers to increase/decrease the volume or mute the
microphone.
ASUS Cerberus 3
