Front View
A
B
C
D
E
F
G
H
Rear View
ST8-S2P-4SX8 / ST8-S2P
12
12
12
7
06. Power switch
07. Power socket
08. SOHOTANK ST8-S2P eSATA interface connection - Upper set
09. SOHOTANK ST8-S2P eSATA interface connection - Lower set
10. SOHOTANK ST8-U5 mini-SAS interface connection - Upper set
11. SOHOTANK ST8-U5 mini-SAS interface connection - Lower set
12. Cooling fan
13. Anti-theft cord slot
Only one interface connection may be used at once per one computer system.
STARDOM SOHOTANK Series User Manual
ST8-S2P-4SX8 / ST8-S2P / ST8-U5
1
1. Hard drive status indicator
2
2. Removable drive tray
3. Key access opening
3
4. Power indicator
4
5. Alarm indicator
5
Drive Position
Upper Set
A. Drive position A -------B. Drive position B
C. Drive position C-------D. Drive position D
4
5
Lower Set
E. Drive position E-------F. Drive position F
G. Drive position G-------H. Drive position H
12
8
12
9
6
12
7
13
Note:
ST8-U5
10
11
6
13
4
