WARNING! Important safety instructions. Carefully read and comply with the
Warnings booklet and Instruction booklet that come with the product as incorrect
installation can cause injury to people and animals and damage to property. They
contain important information regarding safety, installation, use and maintenance.
Keep hold of instructions so that you can attach them to the technical file and
keep them handy for future reference.
1) GENERAL INSTALLER SAFETY
WARNING! Incorrect installation or improper use of the product can result in
injury to people and animals or damage to property.
• Carefully read the "Warnings" booklet and "Instruction booklet" that come
with this product as they provide important information regarding safety,
installation, use and maintenance.
• Dispose of packaging materials (plastic, cardboard, polystyrene, etc.) in
accordance with the provisions of the laws in force. Keep nylon bags and
polystyrene out of reach of children.
• Keep hold of instructions so that you can attach them to the technical file and
keep them handy for future reference.
• The Firm disclaims all responsibility resulting from improper use or any use other
than that for which the product has been designed, as indicated herein.
• Do not install the product in an explosive atmosphere.
• The motor cannot be installed on panels incorporating doors (unless the
motor can be activated when the door is open).
• The units making up the machine and its installation must meet the
requirements of the following European Directives: 2004/108/EEC, 2006/95/
EEC, 98/37/EEC, 99/05/EEC (and later amendments). For all countries outside the
EEC, it is advisable to comply with the above-mentioned standards, in addition
to any national standards in force, to achieve a good level of safety.
• The Firm disclaims all responsibility for failure to apply Good Practice in the
construction of entry systems (doors, gates, etc.) and for deformation that
could occur during use.
• Disconnect the electricity supply before performing any work on the system.
Also disconnect buffer batteries, if any are connected.
• Have the automated system's mains power supply fitted with a switch or
omnipolar thermal-magnetic circuit breaker with a contact separation of at
least 3.5mm.
• Make sure that upline from the mains power supply there is a residual current
circuit breaker that trips at 0.03A.
• Make sure the earth system has been installed correctly: earth all the metal
parts belonging to the entry system (doors, gates, etc.) and all parts of the
system featuring an earth terminal.
• Apply all safety devices (photocells, safety edges, etc.) required to keep the
area free of crushing, dragging and shearing hazards, according to and in
conformity with applicable technical standards and directives.
• Apply at least one warning light (flashing light) in a visible position, and attach
a Warning sign to the structure.
• The Firm disclaims all responsibility for the correct operation and safety of
the automated system if parts from other manufacturers are used.
• Only use original spare parts for any maintenance or repair work.
• Do not make any modifications to the automated system's components unless
explicitly authorized by the Firm.
• Installation must be carried out using safety devices and controls that meet
standard EN 12978.
CHECKING THE AUTOMATED DEVICE
Before the automated device is finally put into operation, perform the following
checks meticulously:
• Make sure all components are fastened securely.
• Check that all safety devices (photocells, safety edge, etc.) are working
properly.
• Check the emergency operation control device.
• Check opening and closing operations with the control devices applied.
• Check the electronic logic for normal (or personalized) operation in the control
panel.
ADJUSTING OPERATING FORCE
WARNING: Check that the force of impact measured at the points
provided for by standard EN 12445 is lower than the value laid down
by standard EN 12453.
Operating force is adjusted with extreme precision by means of the control unit's
electronic control. Operation at the end of travel is adjusted electronically in the
control panel.
To provide good anti-crush safety, the operating force must be slightly greater
than that required to move the leaf both to close and to open it. Whatever the
case, the force, which is measured at the top outer edge of the leaf, must not
exceed the limits laid down by the above-mentioned standards.
CONTROL
There are various options when it comes to the control system (manual, remote
control, access control with magnetic badge, etc.) depending on the installation's
needs and characteristics. See the relevant instructions for the various control
system options.

OPERATING AND INSTALLATION INSTRUCTIONS

Instruct the system's user on the control systems that have been applied and on
how to open the system manually in an emergency.

TROUBLESHOOTING

Gearbox malfunctioning
• Use an appropriate instrument to check for voltage across the gearbox motor
terminals after giving the opening or closing command.
If the motor vibrates but does not rotate, the problem may be:
• Incorrect wiring (see wiring diagram)
• If the leaf moves in the wrong direction, swap over the motor's start connections
in the control unit.
The first command following a mains power outage should be open.
SCRAPPING
Materials must be disposed of in accordance with the regulations in force. There
are no particular hazards or risks involved in scrapping the automated system. For
the purpose of recycling, it is best to separate dismantled parts into like materials
(electrical parts - copper - aluminium - plastic - etc.).
DISMANTLING
Warning: Employ the services of qualified personnel only.
If the automated system is being dismantled in order to be reassembled at another
site, you are required to:
• Cut off the power and disconnect the whole external electrical system.
• See to the replacement of any components that cannot be removed or happen
to be damaged.
2) GENERAL USER SAFETY
• Since the automated device can be remote controlled, hence with the door
out of sight, it is vital that all safety devices be checked frequently to ensure
they are in perfect working order.
• This product has been designed and built solely for the purpose indicated
herein.
Uses not contemplated herein might result in the product being damaged
and could be a source of danger.
• Do not allow adults or children to stand within range of the automated
system.
• Keep remote controls or other control devices out of reach of children in order
to avoid the automated system being operated inadvertently.
This application is not meant for use by people (including children) with
•
impaired mental, physical or sensory capacities, or people who do not have
suitable knowledge, unless they are supervised or have been instructed
by people who are responsible for their safety.
• Users must not make any attempt to work on or repair the automated system
themselves and must instead call in qualified personnel only.
• Anything that is not explicitly provided for in these instructions is not
allowed.
• If the power cord is damaged, it must be replaced by the manufacturer or
their technical assistance department or other such qualified person.
The automated system's proper operation can only be guaranteed if the
information given herein is complied with. The Firm shall not be answe-
rable for damage caused by failure to comply with the installation rules
and instructions featured herein.
Descriptions and illustrations herein are not binding. While we will not
alter the product's essential features, the Firm reserves the right, at any
time, to make those changes deemed opportune to improve the product
from a technical, design or commercial point of view, and will not be re-
quired to update this publication accordingly.
HYDRA N - 13
