Cordless caulking gun
Article number
No-load speed
Max. thrust
Weight approx. (without battery)
Battery
Part number
Rated Voltage
Ratees Capacity
Weight approx.
Battery Charger
Part number
Input Voltage
Output Voltage
Charging current (max.)
Charging time for 1.4 Ah-battery, approx.
Weight approx.
Protection class
A battery that is new or has not been used for a longer
period does not develop its full capacity until after
approximately 2 – 3 charging/discharging cycles.
To remove the battery 7 , press the unlocking but-
tons 6 and pull out the battery toward the rear. Do
not exert any force.
Please refer to the enclosed "Battery Charger"
instructions for the operation of the battery charger
as well as for a description of the charging process.
Indicators and Fault Finding
Indication Red LED Green LED
Mains ON OFF
OFF OFF
Check FLASHING OFF
Charging ON FLASHING Rapid charging active.
Full OFF ON
10
Tool Specifications
AKP 310-C Power
0700 551 X
4 mm/s
3.0 kN
2 kg

Battery Charging

The battery is equipped with an NTC temperature
control which allows charging only within a temper-
ature range of between 0 °C and +50 °C
A significantly reduced working period after charg-
ing indicates that the batteries are used and must be
replaced.
Observe the notes on environmental protection.
Meaning
Charger connected to power
supply, no battery inserted.
No mains voltage, or charger
defective.
No charging.
Battery too hot or cold or
defective. Rapid charging
begins between 0 °C and
+50 °C.
Battery fully charged.
Trickle charging active.
AKP 600-C Power
0700 552 X
4 mm/s
3.0 kN
2.2 kg
NIMH-CX-14,40V/1,4AH
0700 945 430
14.4 V
1.4 Ah
0.625 kg
AL60-CX-NIMH
0700 845
230 V
12 – 18 V
2 A
60 min
0.730 kg
/ II
Remedy
Insert battery.
Check line fuse and socket outlet.
Ckeck charger and battery by a customer
service agent for Würth power tools.
Remove battery from charger and allow
30 minutes before trying to re charge.
The charge procedure of a 1.4 Ah battery
is finished after no later than 70 minutes.
The charger switches to trickle charging.
Battery can be kept in the plugged-in
charger.
