ENGLISH
The Conceptronic 802.11N Clients support WPS (Wi-Fi Protected Setup). WPS is a standard to easily secure
your wireless network. With WPS you can protect your wireless network with just a few easy steps without
knowledge of different encryption options.
Note : To use WPS with your 802.11N Client, you need to have a router or access point which supports
WPS.
5.1 WPS – Push Button connection
• Push the WPS button on your router or access point to enable WPS connection.
• Press and hold the WPS button on your 802.11N Client for about 5 seconds.
Note :
When you have the C300EXi (PCi-Express card), the button is located next to the antenna's on
the back. When you have the C300EXC (PC-Express card), the button is located on the top of
the card.
The Wireless Utility will be triggered by the button and will try to connect to your wireless network. If the
Wireless Utility main window is shown on your screen, you can see the WPS activity at the bottom of the
window:
When the connection is established, the message "WPS status is connected successfully" will be shown:
You are now connected to the wireless network. The Wireless Utility will indicate the signal strength in
your system tray:
5. WPS – Wireless Protected Setup
C300EXi C300EXC
14
