CWT calmat Gebrauchsanweisung Seite 8

8
EN
When the treated water leaves the piping system,
it still carries the scale away as suspended particles.
When drops of water dry in the kitchen and bath-
room the scale powder is left behind. There
are no more hard deposits and residues can be
removed easily with a damp cloth.
cleaning detergents are no longer needed.
Because calmat is installed on the outside of the
pipe and there is no direct contact with the water,
the water is not chemically altered.
minerals and natural elements remain for the
human organism. Food and drinks keep their
natural taste.
General advice
calmat® can be used with any pipe material:
Metal pipes: iron, copper, stainless steel, lead,...
Synthetic/plastic pipes: PVC, PE, PP, compound
pipes,...
- calmat® is applicable to pipe cross sections of
max. 1½ inch (approx. 40 mm)
- Temperature peaks on heating element surfaces
should not exceed ~203°F (~95°C).
- calmat® is absolutely independent from the
velocity of the water
- calmat® functions reliable and has no mainte-
nance costs
Technical Information
Rated voltage:
Rated input:
Voltage supply:
Impulse cables:
Output:
Dimensions (H/W/D):
Max. pipe-Ø:
Safety instructions
Harsh
Important
24 V =
4.3 W
100-240 V~ (50/60 Hz)
2 x 3 m
2 x capacitive
180 x 150 x 50 mm
1½" (40mm)
Attention:
Please read the instruction manual before
installing and starting up the system!
To avoid causing damage, please follow these sa-
fety instructions:
- Connect calmat® only to a correct and firmly
installed earthed safety socket (100–240 V
Hz).
- Do not disconnect from power by pulling the
wire. Always disconnect pulling the plug.
- Do not open the electronic unit.
- The exterior temperature where the unit is
installed should be between -10° C until max. +55°
C.
- The power plug should be kept away from water
drops and water spray.
- Please clean the unit with a damp cloth only
(no detergents).
- Protect calmat® from direct humidity, water and
direct solar radiation.
Installation instructions
The electronic water treatment system calmat®
prevents scale and rust deposits in pipes and de-
vices. The unit is installed on the main water sup-
ply (e.g. close to the water meter) according to the
following instructions:
- The electronic control unit can be attached
directly on to the pipe. This can be done either
horizontally and vertically. It may also be placed
on the wall.
- Wind the impulse cable tightly and firmly wit-
hout gaps around the pipe.
- The impulse cable can also be wound on thicker
connecting pieces (e. g. pipe collars, pipe redu-
cers, compression couplings etc.).
- Before the installation, casing or insulating ma-
terial on the pipe must be removed. Thin coats
of paint can be left.
50/60
~,
