BEHA Unitest Duplex Bedienungsanleitung Seite 13

Table of Contents ............................................Page
1.0 Introduction / Scope of Supply ..........................................14
2.0 Transport and Storage ......................................................14
3.0 Safety Measures ................................................................14
4.0 Operation Elements / Connections and Display ..................16
5.0 Carrying out Current Measurements ..................................17
5.1 Current Measurement by means of the
Closed Current Converter ..................................................17
5.2 Current Measurement by means of open
Current Converter ..............................................................17
5.2.1 Current Measurement within Single-wire ..........................18
Single-Line Conductors ....................................................18
5.2.2 Current Measurement in Flat Strip Conductors ................18
5.2.3 Current Measurement in Single or ....................................19
Multiple-phase Conductors................................................19
6.0 Maintenance ......................................................................19
6.1 Battery replacement ..........................................................19
6.2 Calibration Interval ............................................................20
7.0 Technical Data ..................................................................20
References marked on instrument or in instruction manual:
Warning of a potential danger, comply with instruction manual.
Reference. Please use utmost attention.
Caution! Dangerous voltage. Danger of electrical shock.
Continuous double or reinforced insulation complies with category
II IEC 536.
Conformity symbol, the instrument complies with the valid directi-
ves. It complies with the EMV Directive (89/336/EEC), Standards EN
50081-1 and EN 50082-1 are fulfilled. It also complies with the Low
Voltage Directive (73/23/EEC), Standard EN 61010-1is fulfilled.
The instruction manual contains information and references, ne-
cessary for safe operation and maintenance of the instrument.
Prior to using the instrument (commissioning / assembly) the user is
kindly requested to thoroughly read the instruction manual and comply
with it in all sections.
Failure to read the instruction manual or to comply with the warnings and
references contained herein can result in serious bodily injury or instru-
ment damage.The respective accident prevention regulations established
by the professional associations are to be strictly enforced at all times.
13
