Stanley Stud Sensor S100 Bedieningshandleiding

S100
STHT77403
Stanley Stud Sensor 100
The Stud Sensor 100 uses electronic signals to locate the edges of
studs, joists or live AC wires through drywall or other common building
materials. Once the edge of a stud has been detected, the Stud Sensor
100 displays red LED's and sounds an audible tone. A marking channel
allows you to easily note the stud edges on the wall.
Note: Read all instructions prior to operating the Stud Sensor 100 and
DO NOT remove any labels from the tool.
WARNING:
Protect Your Eyes, Wear Safety Goggles.
1
77403
• Marking Channel
• LED Display
• Live Wire Warning LED
• Activation Button
REV A 08
OPERATING INSTRUCTIONS
Battery
1 Open door on back of unit and connect a 9 volt
battery (not included) to clip. Put battery back into
case and close back battery door.
Note: Recommend to replace a new 9 volt
battery when low battery - fl ashing green LED.
Usage
Detecting Wood / Metal Studs
2 Hold the Stud Sensor 100 fl at
against the surface, making fi rm
contact.
3 Press in and hold the activation
button. The green and top red LED
will light.
Note: The unit cannot be moved
before calibration is complete.
4
unit is calibrated.
5
button during all of the following
procedures.
Note: Once the Activation button
is released, the unit shuts off.
11
Sensor 100 to a different location and try again.
Releasing the activation button will turn off the
• STUD Detected
sensor.
• Live Wire Detected
Note: While calibrating, the Stud Sensor 100
must not be placed directly over a stud, dense
• Self-Calibration Complete /
material such as metal, or over a wet or newly
Low Battery Indicator
painted area, or it will not properly calibrate.
1
9
line. As it detects a stud, the red LED's will go on.
2 3
6
the top LED will go on and an
audible tone will sound. Use the
marking channel located at the top
of the unit to mark the stud edge.
7
the other side of the stud. Coming
from the opposite direction, mark
the other edge of the stud.
4
When the red LED goes off, the
≤ 3
Keep holding the activation
> 3
sec sec
If the red LED stays lit, move the Stud
Slide the Stud Sensor 100 slowly across the surface in a straight
6
When it detects the stud edge,
Repeat the above steps from
5
sec sec
11
11
>3
sec sec
2
9
7
