4. Overview of components and control element

NOTE
Install the GoPro before connecting it to the power
1. Camera support
2. M3 fastening screw
3. Power charger connector
4. Standard mount for GoPro
(1/4 inch inner thread)
5. Mode display
6. Reverse display
1
3
2
4
7
9
8
supply.
7. Micro-USB connection for adjusting settings
and updating the fi rmware
8. On/off switch
9. Battery compartment
10. Power indicator
11. Rotor speed controller
12. Operator buttons (MODE, top, bottom, right,
left)
