N No battery connected.
R Charger ready, battery connected; you can start the
selected mode by pressing the 'START-STOP' but
ton.
C Battery being charged
D Battery being discharged
d/c,d Discharging in DISC=>CHAR mode
d/c,c Charging in DISC=>CHAR mode
c/d,c Charging in CHAR=>DISC mode
c/d,d Discharging in CHAR=>DISC mode
F Finished: selected process completed
W Wait: pause in cycle mode

Supplementary display messages

In order to make the charger as easy as possible to operate, the
screen displays additional messages which keep you informed
of the unit's activities.
However, the screen also provides warning messages, alerting
you to irregularities which may occur when the charger is in use.
In the various operational modes messages appear which are
almost identical, so each one is only explained once in the follo-
wing section.
READY
PRESS (START)
charge or discharge process.
START
CHARGING
It signals to the user that the POWER PEAK INFINITY 2 has
begun charging.
A similar message also appears once the currently selected
activity has begun in one of the other operational modes. In the
second line you will see 'DISCHARGING', 'CHARGE/DISCHAR-
GE' or 'DISCHARGE/CHARGE', depending on the selected
mode.
When you press the 'START' button the cooling fan starts run-
ning in order to dissipate the heat which the charger develops.
The buzzer also sounds twice at this time.
CHARGE
COMPLETED
The same message appears at the appropriate point in the other
modes of operation. In the first line the screen shows 'DISCHAR-
GING', 'CHARGE/DISCHARGE' or 'DISCHARGE/CHARGE',
depending on the selected mode.
Operating instructions
POWER PEAK INFINITY 2
This display appears
as soon as the char-
ger is ready to use,
and a battery is cor-
rectly connected. You
are invited to start the
This message appears
when you have initia-
ted the charge pro-
cess by pressing the
'START/STOP' button.
This display appears
as soon as the auto-
matic charge terminati-
on circuit ends the
charge process.
8
Error messages
NO BATTERY
INSERT BATTERY
re-connect the battery. The display also appears if you press the
'START' button without connecting a battery.
OVERLOAD
PROTECTION
cool down. The POWER PEAK INFINITY 2 's software detects
excessive temperature in the output stage, and interrupts the
charge or discharge process to allow it to cool down. This mes-
sages appears at that time.
INPUT BATTERY
LOW VOLTAGE
below 9.5 V; the charger has interrupted the charge or dischar-
ge process. This message stays on the screen until you elimina-
te the cause of the problem and press any button.
OUTPUT BATTERY
REVERSE POLARITY
This error will not cause damage to the POWER PEAK INFINI-
TY 2 , but in this situation it cannot carry out a charge process.
First you must re-connect the battery with correct polarity, then
you can remove the message by pressing any button.
CHECK THE BATT.
OPEN CIRCUIT
eliminate the cause of the problem and press any button.
The same message also appears if there is an intermittent
contact in the charge lead.
CHECK THE BATT.
SHORT CIRCUIT
nate the cause of the problem and press any button.
CHECK THE BATT
LOW VOLTAGE
Order No.
8294
This message appears
if the battery is dis-
connected when the
charger is in the 'R'
state; it invites you to
This screen message
alerts you to the fact
that the charger has
interrupted the current
activity in order to
allow the charger to
This display indicates
that the input voltage
of the car battery or
mains PSU has fallen
The next message is
the charger's warning
that the battery to be
charged is connected
with reverse polarity.
This message appears
if you disconnect the
battery during the
charge or discharge
process. It stays on
the screen until you
This message indica-
tes a short-circuit
which persists for lon-
ger than one minute.
It also stays on the
screen until you elimi-
This note appears
when you connect a
lead-acid battery and
set the nominal voltage
incorrectly. It stays on
the screen until you
