Screen displays

The settings and measured results for the current charge pro-
cess are displayed on a large backlit two-line screen showing 16
characters per line.
The UP/DOWN keys are used to leaf through the various screen
displays.
Parameters which the charger simply displays (for informa-
tion) are marked by two alternating arrows ' ' and ' '. In con-
trast, those settings which the user can change using the
'+/-' buttons are marked by constantly alternating '+' and '-'
symbols. These special symbols always appear at the end
of the line.
Each screen display includes a status symbol in the right-hand
corner which informs you of the current status of the POWER
PEAK INFINITY 2 .
These status symbols are shown in the sample screen displays
printed in these instructions. The meaning of the symbols is
described in full in the next section.
The following section describes and explains the most important
screen displays.
We have to differentiate here between working displays and
information displays: working displays show all the essential
data at a glance, whereas an info display shows greater detail:
the current operational values during the charge process, and
the parameters you have set during the programming process.
The info display appears when you press one of the four screen
buttons.
1. Working display:
0:34:45 4,24A C
18.73 V +2456mAh
the 'START' button, and it shows all the most important informa-
tion on a single screen.
The example here is typical, and shows that the charge process
has been running for 34 minutes and 45 seconds, and that the
charge current is presently 4.24 A; the battery voltage is current-
ly 18.73 V, and up to now a total of 2456 mAh has been charged
into the pack.
The battery is still being charged (status display C).
The working screen is retained even after the program has
ended.
When a charge program comes to an end (status symbol 'F') the
screen shows the battery voltage when the charge was termina-
ted; in all other modes of operation the screen shows the present
voltage.
If you press the Stop button during the charge/discharge pro-
cess, the info screen appears.
2. Info display:
In the interests of clarity our explanations of the info displays only
show one line of information at a time, although the POWER
PEAK INFINITY 2 always provides the user with two items of
information simultaneously, one on each line.
Operating instructions
POWER PEAK INFINITY 2
The working display
appears on the scre-
en when you press
6
INPUT 13.24V
TX&RX 10.67V
charged (C).
OUTPUT 18.27V
battery continues to be charged (C).
M1 CH. 1238mAh
you can see that the charger has fed 1238 mAh of energy into
the pack. You can leaf through M1 to M5 using the +/- buttons.
The 5 memory spots are erased when you connect a new bat-
tery.
M3 DC. 1167mAh
values (M3), and you can see that the charger has removed
1167 mAh of energy from the pack. You can leaf through M1 to
M5 using the +/- buttons. The 5 memory spots are erased when
you connect a new battery.
PEAK 12.18V
es to be charged (C).
C.TIME 00:18:45
seconds have elapsed since the start of the charge process. The
battery continues to be charged (C).
D.TIME 00:36:23
23 seconds have elapsed since the start of the discharge pro-
cess. The battery continues to be discharged (D).
