Use the centre mount and mast bracket accessories to fix the antenna to the pole (fig.2).
Use the standing supporter accessory to keep the antenna standing on the table for indoor use (fig.3).
For mobile use (boat, caravan etc.) (fig.4).
Connect the "F" male connector of the coaxial cable to the "F" female connector of the antenna and
screw the waterproof cap to the end of the connected "F" connector (fig.5).
F-type connector liking bolt
Coaxial cable
Waterproof kit

Installation:

Installation via a separate AC/DC adapter:
Digital Antenna
AC/DC adapter 12V 50mA
Digital Tuner STB
Power Insert
Fig.2
LOCK
FREE
Fig.3
Fig.4
Fig.5
Waterproof cap
