Step 3:
Place the Alert Notification Switch to "Alert" and you may now activate the
Motion Sensor by pressing the test button on the back of the Motion Sensor.
Please refer to "Walk Testing" for detail information on how to walk test the
Motion Sensor.
Step 4:
Control Panel will respond by flashing the zone LED and alert beeping,
according to the zone number. 1 beep for zone 1, 2 beeps for zone 2 etc. The
beeping will last around 15 seconds for each activation.
After testing, unplug the AC adapter and plugs it back into the Control Panel,
it will back to Normal Operating Mode.
4. Installation
You may now close the battery cover
and re-insert the screw. Mount the
ball-head joint on the wall with
screws provided. Slide the back of
the sensors into the ball-head joint.
The mounting angle can be adjusted.
Walk Testing
Walk test should be performed after the motion
sensor is mounted. Walk in the detected area,
if motion is detected, a red light inside the sensor
will glow. If the red light does not glow, motion has
not been detected and you may need to re-position
the sensor. Ensure you walk test all the locations
that you would like the motion sensor to cover.
12
4. Installation (Cont)
Note:
• Perform the walk test after you have inserted
the battery for more than 1 minute.
• Before performing the walk test, the sensor
should not detect any motion.
• After motion is detected once, the sensor will
not be triggered unless no motion is detected
for 20 seconds. Therefore, wait for at least
20 seconds during walk testing between
2 activations.
False Trigger:
If you experience false triggering, please pay attention to the following.
• When installing the motion sensor, avoid placing it near heat or cold
producing device (i.e. A/C or furnace vents, fans, ovens, space heaters,
etc.) Air movement, especially caused by changes in temperature may
trigger the Motion Sensor and cause false alarms. Please carefully test
your Motion Sensor so that it will only be triggered by wanted movement.
• There is a jumper for sensitivity setting. You may change the sensitivity to
low if you experience false triggering.
Jumper Location 1
Jumper Location 2
5. Operation
The motion sensor is designed to detect the "First Motion". First Motion
means the first movement picked up after 20 seconds without motion
detected. So if you continue to walk in front of the motion sensor, it will only
pick up the first motion. Unless you wait for 20 seconds, then walk again, the
control panel will respond. Otherwise, the control panel will only respond to
the first motion.
Detecting Area:
( Unit = meter)
High Sensitivity
Low Sensitivity
