• If you setup the motion sensor for security purpose where it will cause an
alarm when an intruder break-in, you should program the Motion Sensor to
either Zone 1, 2 or 3. DO NOT program to Zone 4 as it is a dedicated Alert
Zone, sensors in this zone will not cause an alarm.
• If you setup the motion sensor for alert purpose where it does not need to
cause an alarm when motion sensor is detected, you should program the
Motion Sensor to Zone 4. DO NOT program to Zone 1, 2 or 3 as Motion
Sensor in these zones will not provide any alert beeping indication.
Therefore, please select which zone you need to program the Motion Sensor
before proceeding further.
Step1:
Press and hold the Learn Button on the Control Panel for 3 seconds. Control
Panel beeps once and you may release the Learn Button.
Press 3 sec.
Step 2:
Press the zone button (1, 2, 3 or 4) once, for which you want to program the
sensor to. The selected Zone LED will flash.
Press the zone button
10
Long Beep
Zone LED flashing
Step 3:
Activate the Motion Sensor by pressing the test button on the back of the
Motion Sensor.
Press Test Button
Step 4:
You will hear a long beep and the zone LED stops flashing. The sensor is now
programmed to the Control Panel.
Note: You may program up to 4 sensors to on zone.
Zone 4 is an alert zone, sensors in this zone is for alert purpose ONLY and will
not trigger the alarm.
Test Sensor
After programming the motion sensor to the Control Panel, you may place the
Control Panel in Test Mode to verify the communication between the Motion
Sensor and the Control Panel.
Step 1:
Remove the adapter and all batteries from the Control Panel.
Step 2:
Press and hold the "Mute" button and plug the AC adapter back into the
Control Panel. All LED indicators will be ON, you may release the "Mute"
button. Control Panel is now in Test Mode, and it will respond to all Motion
Sensors and other sensors.
Control Panel long beep
Zone LED flashing OFF
11
