Electret condenser microphone head, cardioid polar pattern
LED to display mute or charging status
(refer also to the Synexis charger manuals)
Button with mute function
Arrow-shaped buttons for channel selection and frequency display
OLED display to indicate battery status, channel, frequency and mute function
(on delivery with protective foil)
On/off and Set button
Battery compartment
Gain switch Hi/Low
Lid of the battery compartment
Charging contacts on the right and left hand side
How to insert/replace the batteries
1.
Slide down the lid
2.
Insert the supplied NiMH rechargeable batteries according to the polarity
marks. Before using the transmitter for the first time, the rechargeable
batteries inside must be charged e.g. with the Synexis C8 charger. As an
alternative you can use two 1.5 V AA alkaline batteries.
3.
Close the battery compartment
4.
If the transmitter is not being used for weeks or months, please remove the
batteries. Batteries can leak when not being used for a long time and damage
the device.
How to operate the transmitter
1.
Turn on the handheld transmitter by pressing the on/off button
3 seconds.
2.
The battery status, selected channel and mute function are displayed
3.
If you wish to select a different channel, press the on/off button
of the two arrow-shaped buttons
until the channel display
button
to select the requested channel. The channel will automatically be
stored after approx. 2 seconds. If you press briefly the on/off button
channel will immediately be stored. Make sure that transmitter and receiver
operate on the same channel.
4.
To display the frequeny, press both arrow-shaped buttons
5.
If you wish to select a different mute function, press the on/off button
the mute button
and mute display
requested mute function. After approx. 2 seconds the selected mute function
will automatically be stored or immediately if you press briefly the on/off
button
. If the LED
to open the battery compartment
by sliding the lid
simultaneously for approx. 2 seconds
will flash. Use the upper or lower arrow-shaped
simultaneously for approx. 2 seconds until the channel
will start to flash. Use the mute button
will illuminate blue, the microphone is activated.
.
to the top.
for approx.
.
and one
, the
simultaneously.
and
to select the
