INSTALLATION INSTRUCTIONS

Name of components

Considerate Hint:
1. Insert an ice box into the water tank before installing the honeycomb
filter.
2. When humidifying, water level in the Water Tank must remain under
MAX indication; replenish water if level gets lower than MIN indication.
3. When filling the water tank, make sure that the stopper
and spring are properly positioned.
Foot-Wheel Installation
Water Tank
Circlip
Water Tank Plug
Gently pull out the honeycomb
Foot-wheel
filter from the stand to remove it.
4
Honeycomb Filter
Ice box
Removing the honeycomb filter
Honeycomb Filter
Honeycomb
Filter Frame
