Panel Descriptions

Name
LOOP FX
1
[TYPE] button
[ON/OFF] button
TRACK 1/2
[TRACK 1]/
[TRACK 2] slider
2
STATUS indicator
[SELECT] button
MEMORY
Display
3
[ ] (DOWN)/
[ ] (UP) buttons
[WRITE] button
[DELETE] button
4
1 2
8
Explanation
Selects the LOOP FX type.
Turns LOOP FX on/off.
Adjust the volume of the phrase playback for each track.
Light when tracks 1/2 are in recording or playback mode.
While stopped, they will blink if the track contains data, and will be unlit if
the track contains no data.
These buttons select a track.
This indicates the current phrase memory number, or various other
information.
These decrement or increment the number shown in the display.
Press this to save the recorded phrase to internal memory.
Deletes a phrase from internal memory.
3 4 5
6
7
9
Page
p. 14
p. 8
p. 19
p. 8
p. 10
p. 10
