2 Inserting the DIGITELMO 1 PCMCIA module in the
PCMCIA slot
GB
> As shown in the illustration below, insert the PCMCIA module careful-
ly into the PCMCIA slot, as far as it will go.
Fig. 2.1: DIGITELMO 1 - inserting the module

3 Connecting the antenna with the DIGITELMO 1

> Insert the SMB connector of the rod antenna (supplied) into the
antenna input socket of the DIGITELMO 1
Antenna input
Fig. 3.1: DIGITELMO 1 - module and rod antenna
SMB connector
