INSTALLATION DIAGRAM

Indoor Unit
Drain Piping Thermal Insulation
Wrap the insulated pipe with the
fi nishing tape from bottom to top
Front Panel
Air Filter
(behind the grille)
Air Intake Grille
Air Discharge Louver
To Outdoor Unit
1-3
