TECHNICAL DATA BATTERY CHARGER
Voltage range ................................................ 12 V
Quick charge current .................................... 3.0 A
Maintaining charge ...................................... 500 mA
Battery charging time Li-Ion 1.5 Ah .............. 30 min
Battery charging time Li-Ion 3.0 Ah .............. 60 min
Weight according EPTA-Procedure 01/2003 ..460 g
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Do not dispose of used battery packs in the household
refuse or by burning them. AEG Distributors offer to retrieve
old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only System PCLS chargers for charging System PCLS
battery packs. Do not use battery packs from other systems.
The following battery packs can be charged with this
charger:
voltage battery rated
capacity battery
12 V L1215 ≤ 1.5 Ah
12 V L1220 ≤ 2.0 Ah
12 V L1230 ≤ 3.0 Ah
12 V L1240 ≤ 4.0 Ah
Do not try to charge non-chargeable batteries with this
charger.
No metal parts must be allowed to enter the battery section
of the charger (short circuit risk).
Never break open battery packs and chargers and store
only in dry rooms. Keep dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new
one.
Before use check machine, cable, and plug for any
damages or material fatigue. Repairs should only be carried
out by authorised Service Agents.
This appliance is not intended to
be used or cleaned by persons
with reduced physical, sensory or
mental capabilities, or lack of
experience or knowledge, unless
they have been given instructions
concerning the safe use of the
appliance by a person legally
responsible for their safety. They
should be supervised whilst using
the appliance. Children shall not
use, clean or play with this
appliance, which when not in use
should be secured out of their
reach.
6 ENGLISH
SPECIFIED CONDITIONS OF USE
The quick charger can charge AEG batteries from PCLS to
12 V.
Do not use this product in any other way as stated for
80%
normal use.
90%
MAINS CONNECTION
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
BATTERIES
New battery packs reach full loading capacity after 4 - 5
chargings and dischargings. Battery packs which have not
been used for some time should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure
to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
CHARACTERISTICS
After inserting the battery into the reception of the charger
No. of
the battery will automatically be charged (red LED stays lit,
green LED fl ashes).
cells
When a hot or cold battery pack is inserted into the charger
3
(fl ashing red lamp), charging will begin automatically once
3
the battery reaches the correct charging temperature (Li-Ion
6
0°C...60°C).
3x2
Charging time varies depending on the battery temperature,
charge needed and the type of battery pack being charged.
As soon as charging is completed, the charger switches
over to "trickle" charge to maintain the full capacity (green
control lamp is illuminated continuously)
It is not necessary to remove the battery after charging. The
battery can be stored permanently in the charger without the
danger of being overcharged.
If both LEDs fl ash at the same time, either the battery has
not been completely mounted or there is a fault in the
battery or the charger. For safety reasons you must stop
using the charger and battery immediately and have them
inspected by an AEG Customer Service Centre.
TRANSPORTING LITHIUM BATTERIES
Lithium-ion batteries are subject to the Dangerous Goods
Legislation requirements.
Transportation of those batteries has to be done in
accordance with local, national and international provisions
and regulations.
• The user can transport the batteries by road without
further requirements.
• Commercial transport of Lithium-Ion batteries by third
parties is subject to Dangerous Goods regulations.
Transport preparation and transport are exclusively to be
carried out by appropriately trained persons and the
process has to be accompanied by corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and
insulated to prevent short circuit.
• Ensure that battery pack is secured against movement
within packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice

MAINTENANCE

If the supply cord of this appliance is damaged, it must only
be replaced by a repair shop appointed by the manufacturer,
because special purpose tools are required
Use only AEG accessories and AEG spare parts. Should
components need to be replaced which have not been
described, please contact one of our AEG service agents
(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the Article No. as well as the machine type
printed on the label and order the drawing at your local
service agents or directly at: Techtronic Industries GmbH,
Max-Eyth-Straße 10, 71364 Winnenden, Germany
SYMBOLS
Please read the instructions carefully before
starting.
Do not burn used battery packs.
Do not dispose of electric tools together with
household waste material.
Electric tools and electronic equipment that
have reached the end of their life must be
collected separately and returned to an
environmentally compatible recycling facility.
Check with your local authority or retailer for
recycling advice and collection point.
Never charge a damaged battery pack.
Replace with a new one.
This tool is only suitable for indoor use. Never
expose tool to rain.
Class II tool, tool in which protection against
electric shock does not rely on basic insulation
only, but in which additional safety precautions,
such as double insulation or reinforced
insulation, are provided.
There being no provision for protective earthing
or reliance upon installation conditions.
T3.15A
Anti-surge fuse 3.15 A
European Conformity Mark
National mark of conformity Ukraine
EurAsian Conformity Mark.
ENGLISH 7
