Mounting Installation
Please see the User Manual for detailed instructions regarding installation and mounting
of the camera using a mounting bracket.
D-Link DCS-6511 Quick Install Guide
DCS-6511_A1_QIG_v1.00(EU).indd 3
4. Standard Mounting Instructions
Style 1 - Concealed Cable Installation
ƒ Height: 23 mm (0.9 inches)
ƒ Diameter: 183 mm (7.2 inches)
ƒ Weight: 400 g (0.9 lbs)
Figure 2.2
Figure 2.1
