Hardware Overview; Sd Card Installation - D-Link DCS-6511 Installationsanleitung

24 V Power Connector
Connects to 24 V AC power
Power Connector
Connects to 12 V DC power
Disassemble the Camera
Open the camera enclosure by loosen the
4 screws. Lift the dome off the base of the
camera.
Install the SD Card
Push the SD card into the camera with the
gold contacts oriented towards the base of
the camera. To eject the SD card, push the
SD card into the slot.
2
DCS-6511_A1_QIG_v1.00(EU).indd 2

2. Hardware Overview

Audio In
Connects to a microphone
Ethernet Jack
RJ-45 connector for Ethernet which
can also be used to power the camera
using Power over Ethernet (PoE)

3. SD Card Installation

DI/DO Wiring, 12V DC output
I/O connectors for external devices
Audio Out
Connects to speakers
