Phonix
GB
User manual
For analog playback, the rear panel LINE OUT RCA sockets are
connected to a subsequent stereo amplifier, recorder oder powered
monitors. The signal is output with a fixed level and is not adjusted via
the MONITOR LEVEL control on the front.
The MIX control on the front is used to balance the playback signal
seamlessly between the PRE AMP (the analog inputs on the rear pa-
nel) and the CPU (output signal of the host software in the computer).
Connect the USB TO COMPUTER port of Phonix with an unused
USB 2.0 port on your computer using an USB 2.0 cable (type A-B, no
included). If required, USB bus power can be supplied via this port.
In this case, there is no need for an additional power supply via the
supplied DC adapter.
Choosing Phonix as the audio device for your computer
Phonix is directly supported by the USB audio drivers in Windows (Win-
dows 98 and higher) and Mac OS (Mac OS 9.1 and higher). To record
external audio via Phonix in your software or to play back the output of
the software, you must set Phonix as the input and output device in the
system settings. Proceed as follows:
Windows 98
1) Choose „Settings > Control Panel > Multimedia".
2) Select „USB audio device" as the preferred device for audio input
and output.
Windows XP and higher
1) Choose „Settings > Control Panel > Sounds, Speech and Audio
devices".
2) Select „USB audio device" as the input and output device in the
Audio tab.
or
1) Choose „All Programs > Accessories > Entertainment > Volume
control > Options".
2) Select „USB audio codec" as the Mixer device.
7
