1. KEY DEFINITION FOR FM FUNCTION
No
Key
►║ / ▓
(1)
(2)
MODE
◄◄
(3)
REW
►►
(4)
FF
(5)
REC / EQ
(6)
OP /
A-B
(7)
VOL +
(8)
VOL -
(9
HOLD
2. HOW TO LISTEN TO FM RADIO
If you want to enable the FM radio function, just need to press the "MODE" button to switch to FM
mode. Then you will see the FM display show up.
2.1 Preset channel
2.1.1 Select a desired channel
2.1.2 Press "OP" button to start presetting
2.1.3 While the " FM-Save" sparkling, press FF or REW button to choose the appointed channel and
then press the "play" button to finish the presetting.
Note: you just can set up to 20 channels.
2.2 FM record
2.2.1 Select a desired channel
2.2.2 Press " REC" button to start FM recording.
2.2.3 Press "REC" button again to stop recording.
MINIMUM SYSTEM REQUIREMENTS
Windows 98SE / ME / 2000 / XP.
Pentium 200 MHz or above.
Disk Drive 16MB free hard disk space (to download and upload files from the player).
32MB system memory
USB port (A-Type).
NOTE:
This specification is for the download driver software supplied with this player only. An increased PC specification is likely
to be required for application software for music file creation.
INSTALLING THE DRIVER SOFTWARE
1. To use the player well, we strongly suggest you to execute the set.up.exe on the installation CD under
win98/ME/2000/XP.
2. If you want to use the memory card, ensure that it is correctly inserted in the player.
3. Put the installation CD into CD-ROM Drive and open the "Setup.exe" file, which locates under the directory: / (SD
type:Audio/Multiformat/SD;Flash) While prompted, browse the directory to store software or ignore to continue
installation
4. After installation has completed, connect the USB cable supplied between player USB Port and the USB port of your
PC (or notebook). The computer will then detect the player as a new USB device
5. Click My Computer icon at desktop, you will find two removable "drives" in the My Computer window.
HOW TO USE FM FUNCTION
Description
1) Switch among the preset channels
2) Set the selected channel
3) Press for 3 seconds to turn on/off the player
Switch among music, voice and FM mode
1) Press and hold for two seconds to previous station
2) Press and release to adjust frequency by 50khz.
1) Press and hold for two seconds to next station.
2) Press and release to adjust frequency by 50khz.
1) Record FM voice in FM mode
1) Press to start presetting channel.
Volume up
Volume down
Slide switch to avoid unintentional touch
INSTALLING DRIVER SOFTWARE
5
